NTN 6204LLU/2ASU1 Deep Groove Rolling Bearing 6204ZZCM

> > >

NTN 6204LLU/2ASU1 Deep Groove Rolling Bearing 6204ZZCM

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!
needle roller bearing
CARB toroidal roller bearings
thrust roller bearings
Deep groove ball bearings
Angular contact ball bearings
Thrust ball bearings
Self-aligning ball bearing
Y-bearing
Description
Technical
Application
Pictures

NTN 6204LLU/2ASU1 Deep Groove Rolling Bearing 6204ZZCM


NTN 6204LLU/2ASU1 bearing are machined components that include an outer ring, inner ring, balls, retainers, shields and snap rings. miniature ball bearings are available in inch and metric sizes, open or shielded and flanged or unflanged. For extreme noise sensitive applications, superior hardness and corrosion resistance our ball bearings are manufactured with DD400™ stainless steel material.  Single-row deep groove ball bearings are the most common type of rolling bearings. Their use is very widespread.

Deep groove ball bearings 6204LLU/2ASU1 size information:

6204LLU/2ASU1 NTN brand Ball Bearing 6204 LLU C3 for engine





6204LLU Sealed Ball Bearing, the 6204LLU bearing inner diameter is 20mm, outer diameter is 47mm and the 6204LLU width is 14mm, is a popular size that could be used in many applications, 6204LLU Bearing is made of Chrome Steel,it has 2 Rubber Seals to protect the bearing from dust or any possible contamination, 6204LLU bearing is pre-lubricated with grease.

  • Item: 6204LLU Ball Bearing
  • Type: Deep Groove Ball Bearing
  • Closures: 2 Rubber Seals
  • Lubrication: Self Lubricated (Grease)
  • Dimensions: 20mm x 47mm x 14mm/Metric
  • ID (inner diameter)/Bore: 20mm
  • OD (outer diameter): 47mm
  • Width/Height/thickness: 14mm
  • Size: 20 x 47 x 14 mm
  • Dynamic load rating Cr: 12,800 N
  • Static load rating Cor: 6,600 N
  • Limiting Speed:
  • Grease Lubrication: 11,000 RPM
  • Quantity: One Bearing

Model d/mm D/mm B/mm Weight/KG
6000LLU/ZZ 10 26 8 0.042
6001LLU/ZZ 12 28 8 0.049
6002LLU/ZZ 15 32 9 0.066
6003LLU/ZZ 17 35 10 0.086
6004LLU/ZZ 20 42 12 0.152
6005LLU/ZZ 25 47 12 0.216
6006LLU/ZZ 30 55 13 0.256
6007LLU/ZZ 35 62 14 0.342
6008LLU/ZZ 40 68 15 0.423
6009LLU/ZZ 45 75 16 0.54
6010LLU/ZZ 50 80 16 0.575
6200LLU/ZZ 10 30 9 0.071
6201LLU/ZZ 12 32 10 0.082
6202LLU/ZZ 15 35 11 0.099
6203LLU/ZZ 17 40 12 0.143
6204LLU/ZZ 20 47 14 0.234
6205LLU/ZZ 25 52 15 0.282
6206LLU/ZZ 30 62 16 0.439
6207LLU/ZZ 35 72 17 0.635
6208LLU/ZZ 40 80 18 0.807
6209LLU/ZZ 45 85 19 0.897
6210LLU/ZZ 50 90 20 1.02
6300LLU/ZZ 10 35 11 0.117
6301LLU/ZZ 12 37 12 0.132
6302LLU/ZZ 15 42 13 0.181
6303LLU/ZZ 17 47 14 0.254
6304LLU/ZZ 20 52 15 0.317
6305LLU/ZZ 25 62 17 0.511
6306LLU/ZZ 30 72 19 0.763
6307LLU/ZZ 35 80 21 1.01
6308LLU/ZZ 40 90 23 1.4
6309LLU/ZZ 45 100 25 1.84
6310LLU/ZZ 50 110 27 2.36



All types of Ball bearing models series.

6204 08 JRW3 C3    6204 N
6204 NR        6204 w12 C3   6204 ZZ         6204 ZZ
6204-2NKE      6204-2NKE9    6204-2NSE       6204-2NSE9
6204-2RD       6204-2RS     6204-2RS C3     6204-2RS1
6204-2RS2      6204-2RSH     6204-2RSL       6204-2RSLTN9/HC5C3WT
6204-2RSR     6204-2RU      6204-2Z-N       6204-2Z-NR
6204-2Z.T9H.C3 6204-2Z/VA201 6204-2Z/VA228   6204-2ZNR
6204-C         6204-C-2BRS   6204-C-2HRS    6204-C-2Z
6204-N        6204-NR       6204-RS        6204-RS
6204-RS2       6204-RSH     6204-RSL       6204-TT C3
6204-Z         6204-Z-N     6204-Z-NR       6204-ZNR
6204-ZNR      6204-ZZNR    6204/22         6204/HR11QN
6204/HR11TN    6204/HR22Q2  6204/HR22T2     6204/VA201
6204AG15J30    6204BI        6204C           6204DD
6204DDU       6204DW        6204E           6204EE
6204F600      6204F604      6204F605       6204FT150
6204FT150ZZ    6204G15       6204HT200       6204HT200ZZ
6204HVZZ       6204L11       6204L11-H-20   6204L11-H-20DDU
6204L11-H-20ZZ 6204L11DDU    6204L11ZZ      6204LB
6204LLB       6204LLBNR    6204LLH         6204LLU
6204LLU/22    6204LLUN     6204LLUNR      6204LT
6204LTZZ      6204LU        6204N          6204NSE
6204R         6204UU       6204VV

Application for industrial bearings :

Widely used in metallurgy ,mining ,petroleum,chemical,coal,cement ,paper,windpower,heavy machinery ,enginnering machinery,port machinery and other industries.

a. Auto wheel hub, Auto engine, Auto axle

b. Agricultural machinery, Rotary plow bearings, Tractor, Water pump, Oil engine harvester, Seeder, Tricycle, Farm vehicle, Cultivator

c.Engineering machinery, Excavator, Dozer, Paver, Loader, Hoisting machinery, Piling soil machinery

d. Steel mill machinery, Oil field machinery, Motorship machinery

e. Hardware tool, Electric power tool, Household appliance industry

f. Electronic toys, Fitness equipment, Building machinery

g. Series Of Pumps, Antiseptic Pump, Water pump, Submersible pump, Sewage pump

6204LLU/2ASU1 NTN brand Ball Bearing 6204 LLU C3 for engine

Shipping express we cooperated :

6204LLU/2ASU1 NTN brand Ball Bearing 6204 LLU C3 for engine





Bearing catalog :

6204LLU/2ASU1 NTN brand Ball Bearing 6204 LLU C3 for engine
