NSK RCB121616 Drawn Cup Needle Roller Bearings
Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!
Description
Technical
Application
Pictures
Needle Bearings Description:
Needle roller bearings (needle bearing) is a cylindrical roller with roller bearings, relative to its diameter, roller both thin and long. This is called needle roller. Despite having a smaller cross-section, has a higher load bearing capacity, thin and long needle bearing mounted roller (roller diameter D≤5mm, L / D≥2.5, L is the length of the roller), so radial structure is compact, the diameter size and load capacity of the other types of bearings, minimum diameter, especially for limited radial dimensions of the support structure.With thin and long needle bearing roller (roller length of 3 to 10 times the diameter, the diameter of the generally small 5mm), so the radial structure is compact, its diameter size and load bearing capacity and other types are the same, the outer the minimum diameter, especially for radial mounting dimensions restricted support structure. needle roller bearings based on the use of different occasions, machining accuracy and surface quality should be bearing rings, use combinations. Needle roller bearings are bearing unit consists of radial and thrust needle roller bearings bearing component combinations.
The Specification of One Way Needle Roller Bearing Clutch RCB121616:
| Product | One Way Needle Roller Bearing Clutch RCB121616 |
| Precision Rating | ABEC1,ABEC3,ABEC5 |
| Clearance | C0,C2,C3,C4,C5 is available |
| Sealed Cap | Rubber or Metal |
| OEM | Accept |
| Vibration Level code | V1,V2.V3 |
| Material | Gcr15 |
| Seals Type | ZZ/ZRS.RZ/RS. Open |
| Bore Size |
19.05 mm |
| Outside Diameter | 25.4 mm |
| Thickness | 25.4 mm |
| Regular export packing | Plastic drum+White box+ carton/ industrial packaging or as your requirement. |
RCB series needle bearing sizes:
|
No. |
Weight |
Dimension |
||||
|
Fw |
D |
C |
Rotating Moment |
|||
|
RC(RCB) Needle Roller Clutch Bearing |
||||||
|
RC02 |
2 |
3.175 |
7.15 |
6.35 |
1.5 |
|
|
RC040708 |
3.5 |
6.35 |
11.112 |
12.7 |
1.9 |
|
|
RC040708-FS |
3.5 |
6.35 |
11.112 |
12.7 |
1.9 |
|
|
RC061008 |
4.7 |
9.525 |
15.875 |
12.7 |
4.83 |
|
|
RC061008-FC |
4.7 |
9.525 |
15.875 |
12.7 |
4.83 |
|
|
RC081208 |
9.2 |
12.7 |
19.05 |
12.7 |
7.9 |
|
|
RC081208-FS |
9.2 |
12.7 |
19.05 |
12.7 |
7.9 |
|
|
RC101410 |
14.5 |
15.875 |
22.225 |
15.88 |
15.4 |
|
|
RC101410-FC |
14.5 |
15.875 |
22.225 |
15.88 |
15.4 |
|
|
RC121610 |
17 |
19.05 |
25.4 |
15.88 |
20.9 |
|
|
RC121610-FS |
17 |
19.05 |
25.4 |
15.88 |
20.9 |
|
|
RC162110 |
16.2 |
25.4 |
33.338 |
15.88 |
45 |
|
|
RC162110-FC |
16.2 |
25.4 |
33.338 |
15.88 |
45 |
|
|
RCB061014 |
12 |
9.525 |
15.875 |
22.22 |
4.83 |
|
|
RCB061014-FS |
12 |
9.525 |
15.875 |
22.22 |
4.83 |
|
|
RCB081214 |
16 |
12.7 |
19.05 |
22.22 |
7.9 |
|
|
RCB081214-FC |
16 |
12.7 |
19.05 |
22.22 |
7.9 |
|
|
RCB101416 |
21.3 |
15.875 |
22.225 |
25.4 |
15.4 |
|
|
RCB101416-FS |
21.3 |
15.875 |
22.225 |
25.4 |
15.4 |
|
|
RCB121616 |
26.5 |
19.05 |
25.4 |
25.4 |
20.9 |
|
|
RCB121616-FC |
26.5 |
19.05 |
25.4 |
25.4 |
20.9 |
|
|
RCB162117 |
44.8 |
25.4 |
33.338 |
26.99 |
45 |
|
|
RCB162117-FS |
44.8 |
25.4 |
33.338 |
26.99 |
45 |
|
Micro Bearing Relevant Types:
|
TYPES |
SERIES |
|
Drawn Cup Needle Roller Bearings |
HK, HK…RS, HK…2RS ,BK, BK…RS, TLA, BA, SCE… |
|
One-way Needle Roller Bearings |
HF, HFL, RC, RCB, EWC… |
|
Entity Bushed Needle Roller Bearings |
NA, NK, NKI, NAV, NAO, HJ, BR, BRI… |
|
Yoke TypeTrack Roller Bearings |
RSTO, RSTO…X, STO, STO…X, RNA22…2RS, RNA22…2RSX, NA22…2RS, NA22…2RSX, NATR, NATV, NATV…PP, NATR…PP, NUTR, NUTR…X… |
|
Combined Bearings |
NARF, NARF…L, NKIA, NKIB, ZARN, ZARN…L, NKXR, NKXR…Z, NX, NX…Z, NKX, NKX…Z… |
|
Trust Needle Roller And Cage Assembly |
AXK, AXW, TC, K811, K812, K893, K894, K874, AS, WS811, GS811, LS, ZS |
|
Radial Needle Roller And Cage Assembly |
K, KS, KK, KKS, KZK, KBK, KNL… |
|
Full Complement Needle Roller Bearings |
F, FH, MF, MFH, FY, MFY, B, BH, RNAV, NAV… |
|
Stud Type Track Roller Bearings |
KR, KR…PP, KRE, KRE…PP, KRV, KRV…PP, KRVE, KRVE…PP, NUKR, NUKRE, CR, CF… |
|
Needle Roller |
Dw*Lw, PDw*Lw… |
|
Inner Ring |
IR, LR… |
|
Aligning Roller Bearings |
RPNA, PNA… |
NSK RCB121616 Drawn Cup Needle Roller Bearings:
