SYBR SNL series Plummer block housing bearing SNL516-613
Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!
Description
Technical
Application
Pictures
SYBR SNL series Plummer block housing bearing SNL516-613 enable the incorporated bearings to achieve maximum service life with less need for maintenance. Different housing variants and seal designs are available, making the use of tailored housings virtually unnecessary and enabling cost effective bearing arrangements to be made.
| Housing | da | self-aligning ball bearing | spherical roller bearing | CARB bearing | A | L | H | H1 | Mass | |
| mm | Adapter Sleeve | mm | mm | mm | mm | kg | ||||
| SNL516-613 | 55.562 | 1313 K | HA2313 | 21313 K | - | 120 | 315 | 177 | 95 | 9.5 |
|
housing No. |
Bearing No. |
Bearing No. |
|
SNL507-606 |
1207EK |
2207EK |
|
SNL507-607 |
1307EK |
2307EK |
|
SNL508-607 |
1208EK |
2208EK |
|
SNL510-608 |
1308EK |
2308EK |
|
SNL509 |
1209EK |
2209EK |
|
SNL511-609 |
1309EK |
2309EK |
|
SNL510-608 |
1210EK |
2210EK |
|
SNL512-610 |
1310EK |
2310K |
|
SNL511-609 |
1211EK |
2211EK |
|
SNL513-611 |
1311EK |
2311K |
|
SNL512-610 |
1212EK |
2212EK |
|
SNL515-612 |
1312EK |
2312K |
|
SNL513-611 |
1213EK |
2213EK |
|
SNL516-613 |
1313EK |
2313K |
|
SNL515-612 |
1215K |
2215EK |
|
SNL518-615 |
1315K |
2315K |
|
SNL516-613 |
1216K |
2216EK |
|
SNL519-616 |
1316K |
2316K |
|
SNL 517 |
1217K |
2217K |
|
SNL520-617 |
1317K |
2317K |
|
SNL518-615 |
1218K |
2218K |
|
SNL519-616 |
1219K |
2219K |
|
SNL522-619 |
1319K |
2319K |
|
SNL520-617 |
1220K |
2220K |
|
SNL524-620 |
1320K |
2320K |
|
SNL522-619 |
1222K |
2222K |
|
SNL524-620 |
1224K |
23224CCK/W33 |
|
SNL526 |
22226EK |
23226CCK/W33 |
|
SNL528 |
22228CCK/W33 |
23228CCK/W33 |
|
SNL530 |
22230CCK/W33 |
23230CCK/W33 |
|
SNL532 |
22232CCK/W33 |
23232CCK/W33 |
|
SNL205 |
1205E |
2205E |
|
SNL206-305 |
1305E |
2305 |
SNL plummer block housing bearing accessories for your choose :
1) Spherical roller bearings
2) Adapter sleeves
3) Self-aligning ball bearings
4) Oil seals
5) Locating ring
6) End covers
Application for plummer block bearings :
Bearing housings SNL pillow block bearings packing :
1) Small size plummer block housings are single cartons packing.
2) Big size plummer block housings are wooden case packing
3) Pallates at final .
