SYBR mechanical disc mounting of a deep groove ball bearing 6308-2RS

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!

Description

Technical

Application

Pictures

Deep groove ball bearings can be divided into below Types according to their natures:
A:single row deep groove ball bearings ,
B:double row deep groove ball bearing
C:Full ceramic Single row deep groove ball bearings,
D:stainless steel single row deep groove ball bearings
E:inch deep groove ball bearings,
F:miniature deep groove ball bearings.
G:Thin section deep groove ball bearings.
Features as follows

1. Types:60series,62series,63series,68series,69series,etc.

2. Material: Gcr15-China,(AISI)52100-USA,(DIN)100CR6-Germany

3. Sealing cover: Z, ZZ, RS, 2RS, RZ, ZNR, etc.

4. Vibration and Noisy level: Z1, Z2, Z3 ZV1.ZV2.ZV3,

5. Precision level: ABEC-1, ABEC-3, ABEC-5

6. Main application: motorcycle, motor, pump, sewing machine, textile machine, agriculture machinery, electric, tools, etc.

7. Packing: individual box single plastic bag, cartons and wooden cases

8. Production range: standard and non-standard

We provide deep groove ball bearing as follows:

* 6000 Series - Miniature Bearings -limited space applications

* 6200 Series - Light Series Ball Bearings - Balanced between space and load capacity

* 6300 Series - Medium Series Ball Bearings -heavier load capacity applications

Advantage:

a.Most representative bearing of the rolling bearings

b.Suitable for high speed even extremely high speed

c.Durable, less maintenance frequency

d.Simple structure and low cost

e.Various size and designs

Characteristics		ZZ	2RZ	2RS1
Low friction torque		Good	Good	Fair
High speed		Good	Good	Fair
Sealed grease lubrication		Fair	Good	Excellent
Dust proof		Fair	Good	Excellent
Water proof		Poor	Fair	Good
series	Diameter mm	Variant Structure
61800	10-1200	Z,2Z,RZ,2RZ
61900	10-1000	Z,2Z,RZ,2RZ,N,NR,ZN,RZN
16000	10-1000
6000	10-1000	Z,2Z,RZ,2RZ,RS1,2RS1,N,NR,ZN,RZN
6200	10-1400	Z,2Z,RZ,2RZ,RS1,2RS1,N,NR,ZN,RZN
6300	10-1200	Z,2Z,RZ,2RZ,RS1,2RS1,N,NR,ZN,RZN
6400	10-1200	N.NR
Miniature series	1-10	2Z RS 2RS F6000

Model	d/mm	D/mm	B/mm	Weight/KG
6000ZZ	10	26	8	0.042
6001ZZ	12	28	8	0.049
6002ZZ	15	32	9	0.066
6003ZZ	17	35	10	0.086
6004ZZ	20	42	12	0.152
6005ZZ	25	47	12	0.216
6006ZZ	30	55	13	0.256
6007ZZ	35	62	14	0.342
6008ZZ	40	68	15	0.423
6009ZZ	45	75	16	0.54
6010ZZ	50	80	16	0.575
6200ZZ	10	30	9	0.071
6201ZZ	12	32	10	0.082
6202ZZ	15	35	11	0.099
6203ZZ	17	40	12	0.143
6204ZZ	20	47	14	0.234
6205ZZ	25	52	15	0.282
6206ZZ	30	62	16	0.439
6207ZZ	35	72	17	0.635
6208ZZ	40	80	18	0.807
6209ZZ	45	85	19	0.897
6210ZZ	50	90	20	1.02
6300ZZ	10	35	11	0.117
6301ZZ	12	37	12	0.132
6302ZZ	15	42	13	0.181
6303ZZ	17	47	14	0.254
6304ZZ	20	52	15	0.317
6305ZZ	25	62	17	0.511
6306ZZ	30	72	19	0.763
6307ZZ	35	80	21	1.01
6308ZZ	40	90	23	1.4
6309ZZ	45	100	25	1.84
6310ZZ	50	110	27	2.36
