ASAHI UP003 Zinc Alloy Bearing Unit
Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!
Description
Technical
Application
Pictures
Pillow block bearings introduction:
A pillow block, also known as a plummer block or bearing housing, is a pedestal used to provide support for a rotating shaft with the help of compatible bearings & various accessories. Housing material for a pillow block is typically made of cast iron or cast steel.
The pillow block ball bearing is composed of a single row deep groove ball bearings with seals at both sides and spherical outside surface and a housing, suitable for simple support.
Pillow block bearings are mounted type bearings available in flanged & upright styles in different inch & metric sizes. Pillow block bearings are designed to support shafts. Features include mounting surfaces parallel to shaft axes & elongated bolt holes in bases or feet of units for adjustment & mounting of pillow block bearing. Pillow block bearings are available in bore sizes ranging from 1/2 in. to 10 in.
Pillow block bearings UP003 Details:
|
Model NO. |
UP003 |
|
H(mm) |
24 mm 15/16 in |
|
L(mm) |
85 mm 3-11/32 in |
|
J(mm) |
67 mm 2-41/64 in |
|
Products name |
Pillow Block Bearings |
|
Ring material |
Chrome Steel, Carbon Steel, Stainless Steel, Iron |
|
Material |
GCr15 GCr15SiMn |
|
Type |
SNL, SDG, FSNL, FY, FYC, FYJ, SY, TU, FYTB, SYK, UCP,UCFA, UCF, UCFB, UCFC, UCFL, UCPA, UCPH, UCT, SBPF, SBPFL, SBPP and so on |
|
Precision |
P0 |
|
Clearance |
C0 |
|
Application |
1) Steel Industry 2) Mining&Construction 3) Papermaking Machinery 4) Wind Turbines 5) Machine Tools 6) Gearboxes 7) Pump&Compressors 8) Injection Molding Machines 9) Motorcycles 10) Electric Motors |
Zinc Alloy Bearing Units Drawing and Size Chart:
We provide FL and P series zinc alloy block , also with U000 series or K000 series insert bearings. This kind of bearing housings have the best features, including: small volume, easy installation, light weight, high compressive strength , corrosion resisting, nonmagnetic , etc.
zinc alloy block are mainly usd to food machinery, fitness equipment, mechanical and electrical machinery, and so on.
According to different insert bearings, These housings can be combined into various series produce , UFL series, KFL series, UP series, KP series.
.
Zinc alloy block are one of our competitive products, reliable quality, good appearance, competitive price, complete model and fast delivery.
Pillow block types:
1). Casting vertical pillow block: P
2). Casting high center vertical pillow block: PH
3). Casting narrow vertical pillow block: PA
4). Casting quadrate pillow block: FU
5). Casting convex plate quadrate pillow block: FS
6). Casting rhombic pillow block: FLU
7). Casting adjustable rhombic pillow block: FA
8). Casting convex plate circular pillow block: FC
9). Casting slide plate pillow block: K
10). Casting circlip pillow block: C
11). Casting triangle pillow block: FT
12). Casting suspension pillow block: FB
13). Casting suspended pillow block: HA
14). Pressing vertical pillow block: PP
15). Pressing circular pillow block: PF
16). Pressing triangle pillow block: PFT
17). Pressing rhombic pillow block: PFL
ASAHI Pillow Block Bearing Housing Application:
ASAHI Pillow Block Bearing Pictures:
